Sony PXW-Z300 3-CMOS XDCAM Camcorder

A Closer Look at Sony PXW-Z300

High-operation UHD 4K60 acquisition

At the center of the specification, Packed with broadcast-friendly provides, Sony's PXW-Z300 3-CMOS XDCAM Camcorder uses a 3-CMOS 1/2"-type sensor to capture up to UHD 4K60 footage. It incorporates enhanced AI autofocus, improved network functions, footage authentication, a high-bright, touchscreen LCD side V-mount, adaptable LCD arm, HEVC proxies, and SRT streaming.

Production Workflows and Agile News

Capabilities such as digital signature embedding for authenticity confirmation, efficient file transfer and streaming, and cloud interfacing permit fast, agile news and production processes.

BIONZ XR Processor and 4K Exmor R CMOS Sensors

The PXW-Z300's BIONZ XR picture processor works with the three 4K Exmor R CMOS sensors in real time to capture finely detailed, lifelike pictures with excellent color reproduction, deep depth of field, and very low noise.

17x focal range optics

The 17x zoom lens supplies a 30.3 to 515mm (35mm equivalent) range with a constant f/1.9 highest aperture. A digital extender offers 2x, 3x, or 4x magnification in HD and 1.5x magnification in UHD 4K. The independent focus, iris, and zoom rings let you quickly make manual adjustments without needing to take your eye away from the viewfinder. You can even switch between autofocus and fully manual focus by sliding the focus ring forward or back.

enhanced AI Processing Unit for Autofocus

A dedicated AI processing unit delivers enhanced subject recognition autofocus for the PXW-Z300. The AF can recognize subjects whenever they're facing away from the camera, wearing a mask, are at a far distance or in the shade, or are backlit. Use the auto composition feature to keep your human subjects centered in the frame.

Optical visual Stabilization

Built-in OIS (optical picture stabilization) helps to minimize any blurring or camera shake whenever shooting handheld.

Look Matching: Guide

The PXW-Z300 accommodates S-Cinetone, ITU709, and 709tone looks presets for shooting in SDR (BT.709), plus HLG Live, HLG Mild, and HLG Natural as presets for HDR (HLG) for easy color matching with other Sony cameras. It additionally accommodates custom 3D LUT import for creating your own unique looks.

Format Options and Versatile Recording

• Dual SD card slots, Picture Cache buffering, Interval Recording, and Slow & Quick motion provide versatile capture options.
• Multiple recording formats include UHD 4K and HD at 24 to 60p and 50 and 60i HD selections.
• MXF recording in MPEG HD422 is supplemented by XAVC Intra, XAVC Long, and proxy MP4 options.

Touchscreen LCD: Flexible Arm

The high-bright touchscreen LCD monitor is mounted on an adaptable arm for more comfortable viewing. You can face the monitor forward for vlogging-style viewing, align it with the optical axis of the lens, or move it forward for easy shoulder-mount viewing. A magnifier function lets you enlarge the menu screen at selectable levels.

Side Accessory V-Mount: Guide

The integrated side V-mount delivers a handy spot for attaching devices like a separate PDT-FP1 portable data transmitter, audio receiver, battery, or smartphone. This V-mount additionally incorporates a 1/4"-20 screw adapter.

Remote Control and Wireless Monitoring

Built-in 2.4/5 GHz Wi-Fi lets you check your frame before capture, monitor your shot, and control the camera through the free Monitor & Control app for smartphones and tablets.

Variable ND Filter: Guide

The PXW-Z300's electronically variable ND filter permits on-the-fly exposure adjustments from 1/4 to 1/128 ND without having to change the aperture on the lens or add an outboard filter. An automated ND function maintains an optimum exposure whenever quickly moving between interiors and exteriors.

Comprehensive connections

Multiple interfacing options incorporate up to 12G-SDI feed, switchable timecode in/out, genlock source, and reference output. The PXW-Z300's interface incorporates HDMI, USB-C, LAN, and remote ports, plus a connector for an optional handgrip.

video signal Authentication

The upcoming footage authentication function will use C2PA compliance to maintain the credibility of video footage used in news gathering and field reporting.
NOTE: This feature will only be provided in choose countries and regions.

4-Channel sound

A multi-interface port and XLR sources let you capture up to four channels of audio with automated and dial-based manual level control for each channel.

Network connections

The PXW-Z300 accommodates quick, simple network configuration for managing files from capture to delivery. It uses Wi-Fi or a wired LAN link with support for RJ45, 1000BASE-T, 100BASE-T, and 10BASE-T.

Live Streaming: Guide

Use the PXW-Z300 to stream directly to compatible live-streaming and video-sharing sites via Wi-Fi or a hardwired link. RTMP/RTMPS and SRT protocols make it easy for a single operator to efficiently manage everything from capture to distribution.
Optional paid apps and technologies:

• Connect the camera to the PDT-FP1 Portable Data Transmitter (sold separately) for stable live streaming with QoS using the Creators' app for Enterprise to C3 Portal (paid).
• Use the M2 Live cloud-based switching system for multicamera live production in select countries and regions.

Simple File Transfers: Guide

Upload full-resolution or proxy footage clips to a cloud or FTP server straight from the PXW-Z300's memory card. Once the destination is registered in the camera, files are transferred automatically whenever recording stops.

powering Options

Use widely provided Sony BP-U series batteries or the locking USB-C PD (power delivery) port with a 100W or higher AC adapter to power the PXW-Z300 camera.
