RED DIGITAL CINEMA V-RAPTOR [X] 8K VV Production Pack with Rigid-Hinge Touch 7" (V-Mount)

For the stated surveillance role, The CFexpress Card Reader from RED allows for the fast ingestion of the RED PRO 660GB CFexpress media card on systems that support 20 Gb/s USB 3.2 Gen 2x2. Constructed with a USB Type-C interface, power is received via the USB bus, meaning that no outboard power sources are required. The reader integrates a write-protect switch on the back to protect your data.

Power your KOMODO V-RAPTOR camera with the MICRO-V Battery from RED DIGITAL CINEMA. This 98Wh battery incorporates a space-efficient, lightweight form, up to 12A draw, and data transmission of the remaining time and choose accessory information. Developed in conjunction with battery-maker Core SWX, the space-efficient REDVOLT BP is compatible with choose other cameras whenever used with a full-size V-mount adapter.

Add a direct-mount onboard monitor to your DSMC3 camera rig with the DSMC3 RED Touch 7.0" LCD Monitor with Rigid Hinge from RED DIGITAL CINEMA. The RED Touch contains daylight viewing, a wide 100% DCI-P3 color gamut, and touchscreen control for DSMC3 cameras, such as the V-RAPTOR 8K VV. The rigid hinge and arm permit you to apply more pressure for positioning the Touch for optimal viewing. The Touch monitor incorporates 1920 x 1200 definition, a 1250:1 contrast ratio, and 1300 cd/m² brightness for high-quality image-capture.

This monitor attaches directly to your DSMC3 BRAIN through its Pogo mount, which supplies footage, data, and power to the monitor from the camera. If you need to use the Pogo mount for another accessory, the monitor additionally integrates a locking USB-C connector that alternately permits you to pass footage, data, and power to the camera. Note that the DSMC3 Touch monitor is not compatible with DSMC, DSMC2, RED RANGER, or KOMODO camera systems.

Use the V-RAPTOR Tactical Top Plate with Battery Adapter Plus from RED DIGITAL CINEMA to both securely mount a V-mount battery on your V-RAPTOR BRAIN and power choose camera accessories. This plate makes available one D-Tap and two 2-pin LEMO ports, a pogo connector, a SMBUS pass-through, an E-Fuse safety system, and several 1/4"-20 and 3/8"-16 accessory mounting threads. A 6-pin DC source port can be used to power your camera and accessories simultaneously.

The RED DIGITAL CINEMA V-RAPTOR Top Handle with Extensions provides a complete modular top handle option for the V-RAPTOR, allowing for lightweight or extended wraparound style configurations. It integrates a dedicated start/stop button, ergonomic bocote wood inlays, and several 3/8"-16 and 1/4"-20 mounting points. Additionally, this incorporates the 1", 3", and 5" top handle extension pieces, an elbow piece and a 15mm Monitor Mount.

Mount the RED V-RAPTOR Expander Blade to your V-Raptor camera to gain footage, power, and communication ports, enabling a wide choice in how you configure your camera for professional uses. The Expander Blade attaches to your camera via the camera's 9-pin EXT port and is supported by the included ARCA plate.

Once attached, the Expander plate supplies a BNC connector (Genlock footage), 5-pin connector for timecode, 4-pin connector for RED CTRL, and 3-pin Fischer for Run/Stop. Please note that the 3-pin Run/Stop is only for trigger, and it does not supply power.

Developed for V-RAPTOR camera operators, the RED V-RAPTOR Quick Release Platform Pack is a sturdy yet space-efficient QR plate release system for mounting and balancing your V-Raptor on a tripod. The platform, or baseplate, incorporates 15mm LWS rod clamps and incorporates two 15mm rods, allowing you to use standard lens accommodates and accessories such as matte boxes, follow focus units, lens motors, and more with your V-RAPTOR. The platform slides onto the included dovetail plate and has a lever lock to clamp it in place once you have found the balance point you want.

The platform has a lever lock for clamping the included Arca plate in place, as well as a spring-loaded safety catch to help prevent the Arca plate from accidentally sliding off the platform. The dovetail plate has several 1/4"-20 and 3/8"-16 threaded mounting holes along its length for attaching to a tripod, and the combination of the sliding platform, Arca plate, and dovetail with its several mounting holes enables you to balance a variety of shooting configurations. In addition to supporting your camera, the QR Platform Pack additionally allows optional battery adapter plates, the RED V-RAPTOR Expander Blade, and RED Side Ribs for added versatility.

Add two XLR sources to your V-RAPTOR camera with the RED DSMC3 5-Pin to Dual XLR 3-Pin Adapter. Connect the included 5-pin ODU cable to your camera's ODU port, and the other end of the cable to the adapter's port. The adapter can deliver 48V phantom power and handles both mic and line-level sources. It mounts to the V-Raptor through a 3/8"-26 screw, and has anti-twist pins to prevent it from spinning on your camera. The unit additionally incorporates 6 x M2.5 screw holes for future accessories.

The Side Ribs for V-RAPTOR from RED DIGITAL CINEMA are developed to attach directly to the V-RAPTOR Tactical Top Plate. The two side ribs deliver a multitude of accessory mounting options with multiple 1/4"-20 and 3/8"-16 threaded mounting points, as well as a standard rosette on each side rib. Constructed from sturdy 7075 aluminum, the side ribs collectively weigh just under 6 oz.

Use this pair of Production Grips from RED DIGITAL CINEMA to add two-handed support to your V-RAPTOR side ribs or any camera, baseplate, or cage with ARRI-standard rosette mounts. Made of durable aluminum, each handgrip contains a contoured rubber grip, an extension arm, and anti-twist 1/4"-20 and 3/8"-16 accessory threads. Together, the grip and extension arm deliver two rotation points for setting the grip at the most comfortable angle for your handheld shots.
