SKU: BDLKSDI4K
Blackmagic Design Decklink SDI 4K Capture & Playback Card
Blackmagic Design Decklink SDI 4K Capture & Playback Card
In stock
View full details
WhatsApp us for inquiries
For the stated surveillance role, the Decklink SDI 4K Acquisition & Playback Card from Blackmagic Design provides a single multi-rate SDI source and multi-rate SDI feed. These multi-rate links accept single-link SD, HD, 3G, and 6G-SDI feeds, delivering support for definitions from SD to Ultra HD 4K (3840x2160) and DCI 4K (4096x2160). Additionally, the Decklink SDI 4K incorporates RS-422 deck control, onboard keying, and a reference source.
Decklink SDI 4K supplies adaptable format and platform support, letting you operate with compressed footage formats such as ProRes and DNxHD, as well as 10-bit uncompressed footage. Whenever working with uncompressed footage, all pictures are pixel-for-pixel identical to the source, eliminating any generational loss. This lets you get sharper keying with green displays, cleaner compositions, heightened color correction, and additional. Support for common file formats supplies ready-to-edit files for use in widely chosen editing, effects, and configuration software uses. Decklink SDI 4K is compatible with Mac, Windows, and Linux based workstations.
Decklink SDI 4K supplies adaptable format and platform support, letting you operate with compressed footage formats such as ProRes and DNxHD, as well as 10-bit uncompressed footage. Whenever working with uncompressed footage, all pictures are pixel-for-pixel identical to the source, eliminating any generational loss. This lets you get sharper keying with green displays, cleaner compositions, heightened color correction, and additional. Support for common file formats supplies ready-to-edit files for use in widely chosen editing, effects, and configuration software uses. Decklink SDI 4K is compatible with Mac, Windows, and Linux based workstations.
| Host Connection | PCIe x1 (PCIe 1.0) |
| Video Input Connectors | 1 x BNC (6G-SDI) |
| Input Video Format | SDI (10-Bit 4:4:4/4:2:2) PAL at 50 fps NTSC 59.94 fps 720p 50/59.94/60 fps 1080p 23.98/24/25/30/50/59.94/60 fps 1080PsF 23.98/24/25/29.97/30 fps 1080i 50/59.94/60 fps UHD 4K 23.98/24/25/29.97/30 fps DCI 4K 23.98/24/25 fps DCI 2K 23.98/24/25 fps |
| Video Output Connectors | 1 x BNC (6G-SDI) |
| Output Video Format | SDI (10-Bit 4:4:4/4:2:2) PAL (768 x 576) at 50 fps NTSC 59.94 fps 720p 50/59.94/60 fps 1080p 23.98/24/25/30/50/59.94/60 fps 1080PsF 23.98/24/25/29.97/30 fps 1080i 50/59.94/60 fps UHD 4K 23.98/24/25/29.97/30 fps DCI 4K 23.98/24/25 fps DCI 2K 23.98/24/25 fps |
| Video Standard Compliance | SMPTE 259M/292M/296M/372M/425M/ST-2081 ITU -R BT.601/BT.656 |
| HDCP Support | None |
| Operating Temperature | 41 to 104°F / 5 to 40°C |
| Storage Temperature | -4 to 113°F / -20 to 45°C |
| Certifications | C-Tick, CE, FCC, as per Manufacturer |
| Dimensions | 3.75" / 9.53 cm |
| Weight | 4.5 oz / 128 g |
Key Features
- SD/HD/3G/6G-SDI Input/Output
- PCIe Interface
- UHD / DCI 4K 4:2:2 by Single-Link 6G-SDI
- 1080p 4:4:4 by Single-Link 3G-SDI
- 10-Bit Processing
- RS-422 Deck Control
- Internal Keying
- Reference Input
- Down/Up/Cross Conversions
- Mac OS X, Windows, and Linux Compatible
