CineView SE Wireless WIT04-SE: Guide
Firstly Footage Production company in Dubai finest wireless sdi footage transmitter Dubai Accsoon CineView SE WIT04-SE is a new cable-free footage transmission platform with both SDI and HDMI interfacing Best Wireless Footage Transmitter for camera excellent option of Hollyland Mars 400S PRO.
Definition is up to 1080p60 picture over up to 1200 feet besides it supplies 50ms latency only and a consistent link thanks to dual-band.
Every TX wireless footage unit can stream to a highest of four devices.
This versatile wireless footage transmission system delivers a cost-effective preference of enabling four people on location to display an HDMI and SDI unit signal.
Additionally the transmitter can transmit feed to a total of four devices simultaneously over distances up to 1200' with virtually no latency.
In asset you can Cineview SE WIT04-SE cable-free footage can transmit to a handheld device, the Accsoon Go supporting app for iOS/Android is no-cost to install and use to control and set up the transmission. The receiver additionally provides a USB Type-C UVC feed, so you can connect to a PC and utilize third-party streaming uses to produce wireless live feeds.
The transmitter and receiver deliver multiple power options, comprising a DC barrel source, a L-series battery plate, and a USB Type-C source.
Due to its low-power, fanless configuration, a NP-970 battery can deliver up to 12 hour period of runtime for every unit.
Dual-channel link makes the CineView SE highly resistant to outside interference and maintains that a strong, high-quality feed will be delivered over the 1200' line-of-sight range.
Practical Notes: Receiver Kit and Wireless Camera Transmitter
The kit transmits HD wireless footage and audio to up to four devices (the supplied receiver, mobile phone, tablet, laptop) via dual-band link architecture.
The new USB Type-C port on the receiver will deliver creators, live streamers, and podcasters with much additional power to screen their work or life via live broadcasting.
Dual-Band Transmission Technology: Guide
WIT04-SE Dual-Band (2.4 GHz + 5 GHz) cable-free transmission architecture means you never deliver to worry about footage or audio drop or selector feed issues.
In other words it's Developed for challenging photographers and videographers to experience level and stable shooting, and it incorporates an incredible anti-interference architecture to get exceptional shooting results.
Accsoon CineView SE Long Range, Low Latency: Guide
CineView SE permits operators to experience the support of transmitting pictures and audio fluidly over long range,cf even the size of a football pitch, with a latency of less than 6 ms.
Connect in Multiple Ways: Guide
CineView SE's wireless footage transmitter contains one HDMI and SDI in and one HDMI and SDI loop feed, which can be linked to the body and display, respectively. The HDMI loop feed has been upgraded to zero-latency lossless feed.
Accsoon CineView SE Simplify your Live Streaming: Guide
From the receiver to the PC, you can use a separately provided USB Type-C lead to transfer the footage received by the receiver to any third-party broadcasting platform on your PC for live broadcasting, such as OBS and YouTube, with no extra footage capture devices needed which is already supplied in WIT04-SE.
Accsoon CineView SE WIT04-SE Wireless distance-based Monitoring App Accsoon Go
The Accsoon Go application provides a diverse group of observation contains that can enhance your shooting process.
Enjoy high-end observation provides, allowing you to make control of your workflow acquisition.For instance four perople can display the motion content signal.
powering operation without Hassle
CineView SE can be energized by a DC port or L-series/NP-F battery for up to 12 hour period with a NP-F970 battery.
You can even power CineView SE cable-free footage with a USB Type-C connection for extra convenience.
Noise-Free and Low powering Consumption
CineView SE wireless footage has a very low power consumption and no fan inside, maintaining zero fan interference and a complaint-free sound setting.
Automatic Channel Selection: Guide
At power on, CineView SE will without manual intervention choose the finest channel for audio and footage transmission.
In conclusion The dual-band link technology will additional enhance CineView SE's anti-interference function.
This will maintain that the high-quality audio and FHD footage which can be transmitted with nearly undetectable latency through its dependable signals.
Purchase IT TODAY FROM DUBAIwe service primary of Footage Workflow company in Dubai
locate us:
Showroom
| Projects | Transmitter |
|---|---|
| Video Input | SDI/HDMI |
| SDI Input Format | 1080p 23.98/24/25/29.97/30/50/59.94/60fps Level A/B |
| HDMI Input Format | 1080p 23.98/24/25/29.97/30/50/59.94/60fps |
| DC Port | 5.5mmx2.1mm center positive |
| DC Voltage | 7.4~16.8V |
| Audio | 44.1KHz/48KHz 16bit/24bit PCM |
| Latency | <0.05s (Camera latency not included) |
| OLED Display | 1.3inch |
| Transmission Power | 17~20dBm |
| Transmission Range | 1200ft (No obstacles, no interference) |
| Power Consumption | 4.5Watt (Typical) |
| Operating Environment Temperature | -10~40? |
| Dimensions | 105mmx66mmx32mm (Antennas not included) |
| Weight | 210g (Antennas not included) |
| Projects | Receiver |
| Video Output | SDI/HDMI |
| SDI Output Format | 1080p 24/25/30/50/60fps Level A |
| HDMI Output Format | 1080p 24/25/30/50/60fps |
| DC Port | 5.5mmx2.1mm center positive |
| DC Voltage | 7.4~16.8V |
| OLED Display | 1.3inch |
| Power Consumption | 3.5Watt (Typical) |
| Operating Environment Temperature | -10~40? |
| Dimensions | 105mmx66mmx32mm (Antennas not included) |
| Weight | 210g (Antennas not included) |
Key Features
- Wireless Transmitter/Receiver Units
- HDMI and SDI input
- Transmit to Receiver + 3 Devices
- Mix up to 4 Receivers, Tablets & Phones
- 1200' 1080p60 HDMI Transmission
- USB Type-C UVC Output for Live Streaming
- iOS/Android App for Configuration
- Dual-Channel Livestream Transmission
- 12-Hour Battery Life, 1.3" OLED Displays
- USB & DC Input, L-Series Battery Support
- 2 x Shoe Mount Adapters Included
